Nice work. Can you explain the button and D-pad spacers? Did you find the button/pad a little loose and was button spacer used on all 4 or just x and y? Was the top LCD bracket glued to the LCD? Thanks.

Hoolyhoo,

I bought your button set a while ago and I'm looking to move to a new shell. Since my PCB is already soldered is there a template I can 3d print?

Jeff

Yeah. Please post them all. I'd love the GB and 3ds versions.

As I recall there was some arduino code you can edit to dim the screen further, but the wiki is not updated yet. I'm not sure if there is a way to disable to backlight or is lowering further the best option. If someone has an idea on how to disable the LCD backlight I'd be interested in it.

Thanks Diesel. I was hoping I missed a trick or two to ensure alignment, but other than patience and time not much else to do. I may try to print a new screen bracket, but that would require disassembly again. I guess I'll try to live with with for longer, but man I do love this system.

Jeff

The problem is not over scan or similar. It's the actual physical alignment of the screen. In the attached image you can see the top boarder is higher on the left. The is also apparent on text.

So the screen for my CSO has been misaligned since day one. Its finally gotten to me and needs fixed. I'm using a Helders AIO screen bracket. Any recommendations on making sure its aligned?

Jeff

Confirmed that the new version 1.3.0 is needed with newest arduino flash for OSD and power button to function. No issues so far with the new versions.

I tried updating the Arduino via the RPI, but the I recieved an error regarding the OSD (don't recall exact wording). I then tried updating via PC. I changed the hardware to 1.1E and it flashed okay, but know I have no OSD and the power button does not shutdown the CS. I'm still running version 1.1....

The website indicates the HDMI is optional can you clarify what that means? Is the adapter separate and should be requested as a custom design or is it just an option to install during the build?

Also does the HDMI output 1080P or is it just a mirrored version of the display?

jeff
