I ran into an issue on my first gbz build with the pi getting so hot that it would soften up the hot glue that i used to mount it, enough that i couldnt plug in a mini hdmi cord. If i have been running the gbz for some time (enough for the pi to get hot) i would try to plug in a mini hdmi and it would just push the whole pi inward. I came up with a more solid and permanent solution but still easily removable. Best of all, it fits perfectly on helders AIO board. Hope this will help someone here out
- Attachments
-
- Finished product.
- IMG_20170407_100656.jpg (2.67 MiB) Viewed 10527 times
-
- Shorten the two bottom screws so that it doesnt bottom out and possibly damage the AIO.
- Screenshot_20170407-115111.png (1.76 MiB) Viewed 10527 times
-
- Screw the screw posts onto the pi.
- Screenshot_20170407-115021.png (3.61 MiB) Viewed 10527 times
-
- Carefully trim the screw posts to size and test fit in place in the housing. Use high temp epoxy to glue down the screw posts while theyre still screwed onto the pi and let it cure.
- Screenshot_20170407-114617.png (2.91 MiB) Viewed 10527 times
-
- Shot of the screw posts with the pi removed.
- Screenshot_20170407-114259.png (2.52 MiB) Viewed 10527 times
-
- Pi mounted neatly
- IMG_20170407_100656.jpg (2.67 MiB) Viewed 10527 times
- Lphillimore
- Posts: 993
- Joined: Sat Jan 07, 2017 7:03 pm
- Location: Perth, WA
- Has thanked: 796 times
- Been thanked: 527 times
Re: A better mounting solution for pi zero in GBZ
Nice one - much cleaner and allows for more airflow and for it to be removed
mintyPi Giveaway [CLOSED]:
http://www.sudomod.com/forum/viewtopic.php?f=38&t=3456
Builds:
GBZ
http://www.sudomod.com/forum/viewtopic.php?f=9&t=2838
mintyPi
http://www.sudomod.com/forum/viewtopic.php?f=32&t=3468
Kite SAIO
http://www.sudomod.com/forum/viewtopic.php?f=9&t=3075
Dreamcast VMU
https://sudomod.com/forum/viewtopic.php ... 133#p62133
http://www.sudomod.com/forum/viewtopic.php?f=38&t=3456
Builds:
GBZ
http://www.sudomod.com/forum/viewtopic.php?f=9&t=2838
mintyPi
http://www.sudomod.com/forum/viewtopic.php?f=32&t=3468
Kite SAIO
http://www.sudomod.com/forum/viewtopic.php?f=9&t=3075
Dreamcast VMU
https://sudomod.com/forum/viewtopic.php ... 133#p62133
- drafterITA
- Posts: 120
- Joined: Fri Feb 24, 2017 8:15 am
- Location: Italy
- Has thanked: 66 times
- Been thanked: 19 times
- Contact:
Re: A better mounting solution for pi zero in GBZ
That's very nice..
I'm a bit concerned by using epoxy to glue the screwposts on the AIO.. But it's a way nicer solution than glueing the pi down..
You used the removed screwposts from the front part of the case right? The ones removed to make space for the screen..
Well done
I'm a bit concerned by using epoxy to glue the screwposts on the AIO.. But it's a way nicer solution than glueing the pi down..
You used the removed screwposts from the front part of the case right? The ones removed to make space for the screen..
Well done
Cheers!
drafterITA
drafterITA
- correia5022
- Posts: 202
- Joined: Mon Dec 05, 2016 12:32 am
- Location: Portugal
- Has thanked: 17 times
- Been thanked: 38 times
Re: A better mounting solution for pi zero in GBZ
Very cool!! Nice eye
________________________________________
Starting on electronics
My first build, 2 years later
https://sudomod.com/forum/viewtopic.php ... 8&start=30
Check out my Boombox: https://nrcboombox.wixsite.com/website
Starting on electronics
My first build, 2 years later
https://sudomod.com/forum/viewtopic.php ... 8&start=30
Check out my Boombox: https://nrcboombox.wixsite.com/website
- drafterITA
- Posts: 120
- Joined: Fri Feb 24, 2017 8:15 am
- Location: Italy
- Has thanked: 66 times
- Been thanked: 19 times
- Contact:
Re: A better mounting solution for pi zero in GBZ
Cool! I'm going to try that too
Cheers!
drafterITA
drafterITA
- jostie94
- Posts: 51
- Joined: Sat Apr 01, 2017 3:34 am
- Location: the netherlands
- Has thanked: 5 times
- Been thanked: 28 times
Re: A better mounting solution for pi zero in GBZ
i did the same on my project, on the other half of the shell.
SpoilerShow
my GBZ builds:
1) http://www.sudomod.com/forum/viewtopic.php?f=9&t=3197
------------------------------------------------------------------------------------------
1) http://www.sudomod.com/forum/viewtopic.php?f=9&t=3197
------------------------------------------------------------------------------------------
Re: A better mounting solution for pi zero in GBZ
I'm so glad I saw this! Great job! I'm definitely gonna use this.
Re: A better mounting solution for pi zero in GBZ
Thanks for the post, im at this part of the build and can get everything to fit right. How did you get everything to fit, did you have to remove the battery compartment?
My bartop Arcade
http://www.sudomod.com/forum/viewtopic.php?f=13&t=3107
My GBZ (Henry)
http://www.sudomod.com/forum/viewtopic.php?f=9&t=3281
Headless Setup (no usb port required)
http://www.sudomod.com/forum/viewtopic.php?f=20&t=3289
http://www.sudomod.com/forum/viewtopic.php?f=13&t=3107
My GBZ (Henry)
http://www.sudomod.com/forum/viewtopic.php?f=9&t=3281
Headless Setup (no usb port required)
http://www.sudomod.com/forum/viewtopic.php?f=20&t=3289
Re: A better mounting solution for pi zero in GBZ
Sorry for the late reply. I had to trim the battery compartment just a little in the upper right corner. Just enough to free up some space for the pi zero.
