Mischief · Post by **Mischief** » Tue Aug 09, 2016 3:12 am

Just need to install the battery parts (PowerBoost, Safe Shutdown and battery) and it will be complete, Will be taking internal pics as soon as its all done but here are some pics of it all shut up.

[spoiler="open me for pics"]

Made it to match my car

[/spoiler]

Mischief · Post by **Mischief** » Fri Aug 19, 2016 7:40 am

Quick pic of the inside before I fit the Powerboost 1000c and battery:

[spoiler="click me for pics"]

[/spoiler]

USB hub and Wifi adapter sit above the PiZero, i'm using the factory power socket, headphone socket and switch. The teensy lc is hidden behind the screens ribbon cable, I have run this from a 1A usb phone charger for a few hours and I have had no issues with freezing or crashing.

My Powerboost should be here Monday so will be working on that as soon as it arrives

Mischief · Post by **Mischief** » Thu Sep 08, 2016 12:52 am

Battery compartment done, it is a temp install as I want to extend the led's to the contrast port and will be installing the safe shutdown PCB I just needed to test the battery out to make sure it all ran ok.

Played it for 2 hours straight yesterday so all is well

[spoiler="images"]

[/spoiler]

PolletjeNL · Post by **PolletjeNL** » Thu Sep 08, 2016 4:25 am

Nice solution!!

, almost the same as where I am going for with the battery compartment.

Rolen47 · Post by **Rolen47** » Thu Sep 08, 2016 5:03 pm

Where did you get the battery and what are it's dimensions? It looks like it fits very nicely.

Mischief · Post by **Mischief** » Thu Sep 08, 2016 11:45 pm

Rolen47 wrote:Where did you get the battery and what are it's dimensions? It looks like it fits very nicely.

Got it here:

http://r.ebay.com/FrhAj3

Dimensions are on the listing.

Mischief · Post by **Mischief** » Mon Sep 19, 2016 8:40 am

Complete redesign as I have snagged an AIO board on the recent pre order, will be putting the power strip (board by helder ordered from OSH park) in with the powerboost under the battery and I have removed the usb hub, audio parts and teensy in preparation.

Will be taking more pics as soon as everything arrives.

beerman · Post by **beerman** » Mon Sep 19, 2016 10:49 am

Wow, looks very nice. I too am doing yellow and black.

beerman · Post by **beerman** » Mon Sep 19, 2016 10:54 am

I was thinking of a black cart too but will now get a yellow one I think just because I don't want to replicate your one.

Mischief · Post by **Mischief** » Mon Sep 19, 2016 10:56 am

beerman wrote:I was thinking of a black cart too but will now get a yellow one I think just because I don't want to replicate your one.

Replicate away, I don't mind at all I just want mine finished
